HaoZhong Carbon Fiber Products

Wholesale sales 10-20Pcs OD 31mm - OD 40mm X 500MM 100% Roll Wrapped Carbon Fiber Tube 3K /Tubing Plain/Twill Glossy/Matte

Wholesale sales 10-20Pcs OD 31mm - OD 40mm X 500MM 100% Roll Wrapped Carbon Fiber Tube 3K /Tubing Plain/Twill Glossy/Matte

Regular price $192.15 USD
Regular price $0.00 USD Sale price $192.15 USD
Sale Sold out
Shipping calculated at checkout.
Size
Quantity

Bulk customization contact: wh59ok@gmail.com




Roll Wrapped High Performance Carbon Fibre Tube 3k For Use In Projects Requiring Enhanced Strength In Multiple Axis.

Whether your project is big or small, we are bound to have round carbon fiber tubing that suits your needs. As an added bonus we are generally able to ship right away on most products listed in our store! Aside from aesthetic variations of our many round stock tubes, you might also wish to consider their superb mechanical properties as well. That is after all the main reason we love carbon fiber so much! Of course it's an added bonus that it looks incredible too.

Roll wrapped tubing is manufactured using multiple layers of prepreg carbon fiber (and if noted, other) materials. In general each layer is about 0.006 inches thick which means that a tube with a wall thickness of 0.060 inches will typically be composed of 9-10 individual layers of carbon fiber. The number of layers (plys) allows us to vary the orientation of the fibers throughout the thickness, creating a high performance, engineered product.

Mechanical Properties & Specification

The Tube Is Available The Following Lengths: 500mm-5000mm. If You Have A Large Order We Can Produce.

Internal Diameter (ID, mm) Outer Diameter (OD, mm)

Wall Thickness (mm)

Length (mm)

Weight g/m

29 32 1.5 500 221
30 32 1.0 500 140
30 33 1.5 500 235
32 34 1.0 500 157
25 35 5.0 500 713
32 35 1.5 500 218
33 35 1.0 500 164
30 36 3.0 500 446
34 36 1.0 500 170
34 38 2.0 500 340
35 38 1.5 500 246
36 38 1.0 500 178
34 40 3.0 500 508
35 40 2.5 500 445
36 40 2.0 500 353
37 40 1.5 500 290
38 40 1.0 500 178

 These tubes are on hot sale ,If you make larger order, we could give you favorable price.

Composition

Roll wrapped tubing is manufactured using multiple layers of prepreg carbon fiber (and if noted, other) materials. In general each layer is about 0.006 inches thick which means that a tube with a wall thickness of 0.060 inches will typically be composed of 9-10 individual layers of carbon fiber. The number of layers (plys) allows us to vary the orientation of the fibers throughout the thickness, creating a high performance, engineered product..

Comparison With Steel And Aluminium Tube



Propertyth> CF Fabric (50% at 0°/50% at 90°) CF Uni-Directional Steel Aluminium
Density (g/cc) 1.60 1.60 8.0 2.7
Youngs Modulus 0°(GPa) 70 135 207 72
Youngs Modulus 90°(GPa) 70 10 207 72
Ult. tensile Strength 0°(MPa) 600 1500 990 460
Ult. comp. Strength 0°(MPa) 570 1200 990 460
Ult. tensile Strength 90°(MPa) 600 50 990 460
Ult. comp. Strength 90°(MPa) 570 250 990 460

Applications

  • Automotive
  • Light Aircraft Tubing
  • Construction
  • Duct rod / Fish rods
  • Aerospace Instrument & Interior Supports
  • Photography & Sound Booms
  • Outer Space & Terrestrial Antennae Supports
  • Corrosion Resistant Equipment Marine
    • Sporting Goods
    • Oil & Gas
    • Robotic Arms & Supports
    • Power Generation
    • Window Shades
    • Wastewater Treatment
    • Advertising Panels
  •
