HaoZhong Carbon Fiber Products

OD 11mm - 20mm X Length 1000MM 100% Roll Wrapped Carbon Fiber Tube 3K /Tubing Plain/Twill Glossy/Matte

OD 11mm - 20mm X Length 1000MM 100% Roll Wrapped Carbon Fiber Tube 3K /Tubing Plain/Twill Glossy/Matte

Normaler Preis $11.55 USD
Normaler Preis Verkaufspreis $11.55 USD
Sale Ausverkauft
Versand wird beim Checkout berechnet
Size
Quantity

Bulk customization contact: wh59ok@gmail.com



Roll Wrapped High Performance Carbon Fibre Tube 3k For Use In Projects Requiring Enhanced Strength In Multiple Axis.

Whether your project is big or small, we are bound to have round carbon fiber tubing that suits your needs. As an added bonus we are generally able to ship right away on most products listed in our store! Aside from aesthetic variations of our many round stock tubes, you might also wish to consider their superb mechanical properties as well. That is after all the main reason we love carbon fiber so much! Of course it's an added bonus that it looks incredible too.

Roll wrapped tubing is manufactured using multiple layers of prepreg carbon fiber (and if noted, other) materials. In general each layer is about 0.006 inches thick which means that a tube with a wall thickness of 0.060 inches will typically be composed of 9-10 individual layers of carbon fiber. The number of layers (plys) allows us to vary the orientation of the fibers throughout the thickness, creating a high performance, engineered product.

Mechanical Properties & Specification

The Tube Is Available The Following Lengths: 500mm-5000mm. If You Have A Large Order We Can Produce.

Internal Diameter (ID, mm) Outer Diameter (OD, mm)

Wall Thickness (mm)

Length (mm)

Weight g/m

9.0 11.0 1.0 1000 49
8.0 12.0 2.0 1000 97
10.0 12.0 1.0 1000 50
11.0 12.0 0.5 1000 27
11.0 13.0 1.0 1000 55
10.0 14.0 2.0 1000 116
12.0 14.0 1.0 1000 60
13.0 14.0 0.5 1000 30
10.0 15.0 2.5 1000 151
12.0 15.0 1.5 1000 96
13.0 15.0 1.0 1000 64
12.0 16.0 2.0 1000 131
13.0 16.0 1.5 1000 105
14.0 16.0 1.0 1000 70
15.0 16.0 0.5 1000 38
13.0 17.0 2.0 1000 136
15.0 17.0 1.0 1000 76
14.0 18.0 2.0 1000 152
15.0 18.0 1.5 1000 122
16.0 18.0 1.0 1000 79
17.0 18.0 0.5 1000 41
15.0 19.0 2.0 1000 162
16.0 19.0 1.5 1000 126
17.0 19.0 1.0 1000 84
14.0 20.0 3.0 1000 250
16.0 20.0 2.0 1000 174
17.0 20.0 1.5 1000 130
18.0 20.0 1.0 1000 93
19.0 20.0 0.5 1000 48

 These tubes are on hot sale ,If you make larger order, we could give you favorable price.

Composition

Roll wrapped tubing is manufactured using multiple layers of prepreg carbon fiber (and if noted, other) materials. In general each layer is about 0.006 inches thick which means that a tube with a wall thickness of 0.060 inches will typically be composed of 9-10 individual layers of carbon fiber. The number of layers (plys) allows us to vary the orientation of the fibers throughout the thickness, creating a high performance, engineered product..

Comparison With Steel And Aluminium Tube



Propertyth> CF Fabric (50% at 0°/50% at 90°) CF Uni-Directional Steel Aluminium
Density (g/cc) 1.60 1.60 8.0 2.7
Youngs Modulus 0°(GPa) 70 135 207 72
Youngs Modulus 90°(GPa) 70 10 207 72
Ult. tensile Strength 0°(MPa) 600 1500 990 460
Ult. comp. Strength 0°(MPa) 570 1200 990 460
Ult. tensile Strength 90°(MPa) 600 50 990 460
Ult. comp. Strength 90°(MPa) 570 250 990 460

Applications

  • Automotive
  • Light Aircraft Tubing
  • Construction
  • Duct rod / Fish rods
  • Aerospace Instrument & Interior Supports
  • Photography & Sound Booms
  • Outer Space & Terrestrial Antennae Supports
  • Corrosion Resistant Equipment Marine
    • Sporting Goods
    • Oil & Gas
    • Robotic Arms & Supports
    • Power Generation
    • Window Shades
    • Wastewater Treatment
    • Advertising Panels
  •
